DB Drive Euphoria XPERT EX9.2 1800

Features

• Audiophile Grade tiffany RCA connectors
• Selectable Low-Pass, Band-Pass or High-Pass x-over
• High efficiency full range Class D Technology
• Direct Connect Speaker Terminals
• Large Gauge Power Wire Inputs
• Speaker Short Circuit Protection
• Bridgeable @ 4 ohms
• Conformal coated moisture resistant PCB

Voltage

• 4Ω @ 14.4V:   2x500
• 2Ω @ 14.4V:   2x750
• 4Ω (Bridged)  1x1800

Specifications

• Working Voltage: 10-16Volts
• Freq Response 20HZ-30kHz
• Signal to Noise Ration <95dB
• Damping Factor 150 dB<
• Low Level Input 6C-.2V
• HP Filter 20Hz-5kHz
• LP Filter 50Hz- 5kHz
